White & Blue MaxTow Transmission Temperature Gauge

Your Price: $89.99

Item Number:
MT-WBDV12
UPC:
842559100837
Gauge Series:
White & Blue MaxTow Series
Gauge Type:
Transmission Temperature
Range of Reading:
80 - 260° F
Face Color:
White
Size:
52mm
Lens:
Clear
Backlighting Color:
Blue
Sending Unit:
Electronic
Measurement Unit:
Standard
Display:
Combo
Instructions:
/content/instructions/gauges/MT-DV12.pdf
GoogleTitle:
MaxTow 260F Transmission Temperature Gauge Kit - Double Vision | Digital & Analog Readings - Electronic Sensor - White Dial | Blue LED - 2-1/16"
In Stock & Ready to Ship Most Orders Placed by 3PM EST Ship Same Day (Except Weekends & Holidays)
  • Free Shipping Over $50

    Free Shipping Over $50

  • Easy Returns

    Easy Returns

  • Free In-House Support

    Free In-House Support

  • One Year Limited Warranty

    One Year
    Limited Warranty

  • Overview

    MaxTow’s Double Vision™ White & Blue Transmission Temperature Gauges are electronically driven truck gauges that include an electronic temperature sensor which reads and displays transmission temps from 80° to 260° Fahrenheit with unrivaled accuracy. Our trans temp gauge allows you to easily monitor these changing automatic transmission temperatures, ensuring your transmission doesn’t overheat and cause major damage. This transmission gauge was made for any truck with an automatic transmission that is towing heavy loads or traveling long distances. Get ready to hit the road and Tow to the Max™

    MaxTow White & Blue Double Vision Gauges MaxTow White & Blue Double Vision Gauges

    MaxTow’s White & Blue Double Vision™ Gauge Series features a white gauge dial and blue LED display with an illuminated red needle. You get the classic look of an analog gauge combined with a blue digital numerical readout. This 2-1/16” (52mm) ATF temperature gauge outperforms the competition with features like stepper motor technology which allows for all needle movement to be exceptionally smooth and all gauge readings to be extremely accurate. Brightness Recall remembers the previous brightness setting before powering down your truck.

    MaxTow White & Blue Double Vision Transmission Temperature Gauges MaxTow White & Blue Double Vision Transmission Temperature Gauges

    MaxTow’s trans temp gauge kit features sensor and power harnesses with extended lengths for added flexibility during installation. The sensor harness is 9’ with a waterproof connector and the power harness is 5’, assuring you’ll have more than enough wiring for the trans temp gauge install. Easily attach both harnesses to the back of the gauge by utilizing seamless Plug and Play connectors.

    Transmission Oil Temperature Gauge

    • 2-1/16” (52mm) Transmission Temperature Gauge
    • 1/8-27 NPT Transmission Oil Temperature Sensor with Waterproof Connector
    • 9' Sensor Wire Harness with Waterproof Connector
    • 5’ Power Harness
    • ATF Temperature Gauge Visor
    • Mounting Bracket
    • Mounting Bracket Hardware
    • Installation Instructions
    MaxTow White & Blue Dimming Modes

    This automatic transmission temperature gauge features innovative Daytime and Nighttime Dimming Modes with three customizable brightness settings (Low, Medium, High) for each mode. This gives you multiple dimming options, allowing you to set your individual preference when hitting the road during the day or later on at night. Adjust for the right amount of brightness as you’re taking readings.

    Why Is A MaxTow Diesel Truck Trans Temp Gauge So Important?

    One of the major factors in reducing the life of a vehicle’s transmission is overheating, and one of the main reasons a truck transmission overheats is due to the strain of towing larger and heavier amounts of cargo. MaxTow’s automatic trans temp gauge will monitor transmission oil temp during a larger haul and alert you in the event of ATF temperature spikes. Another issue is older transmission fluid. Older transmission fluid will be less effective at performing its primary functions, one of the most important of which is keeping the system cool.

    MaxTow Guarantee

    MaxTow Gauges is your source for cutting-edge aftermarket automotive products specially designed for gas and diesel trucks. Shop with confidence knowing all purchases are backed by a One Year Limited Warranty and Free Lifetime Tech Support. You will also have access to an unrivaled customer support experience in the event you have any questions about our gauges, pods and accessories. Established in 2012 by truck owners for truck owners, we remain dedicated to getting the most out of any truck. Get ready to hit the road and Tow to the Max™

    Tech Specs
    Range of Reading: 80° - 260° Fahrenheit
    Diameter of Gauge: 2-1/16" or 52mm
    Depth of Gauge: 1-5/16" or 33mm
    12-Volt Power Required:
    Power Wire Harness Length: 5'
    Sensor Wire Harness Length: 9'
    Included Parts List: Power Harness, Sensor Harness, Temperature Sensor, Mounting Hardware, Gauge Visor & Instructions
    Sensor Thread Size: 1/8-27 NPT
    Actual Sensor Size: 5/8" Diameter
    Power Harness Gauge Size: 18 Gauge
    Instructions

    Includes an installation guide which is available online and included with your order. You can also visit our library of installation videos which include complete step-by-step tutorials and useful tips on how to install a wide range of MaxTow products.

    Download and Print the PDF PDF Instructions
